High Precision Tensile Strength Testing Machine with 6 Stations and 0~40A Load Current for Cable and Wire Testing

ブランド名:	HongCe
モデル番号:	HDX1314
MOQ:	1セット
価格:	Negotiatable
支払条件:	T/T
供給能力:	1ヶ月あたりにセット20

詳細情報

製品の説明

詳細情報

起源の場所:

中国

証明:

Third part calibration certificate(cost additional)

標準:

UL817

場所:

電流をロードします:

0~40A 任意調節可能

負荷電圧:

4~12V

保証:

1年

周囲温度:

0〜40℃

周囲の湿度:

85%以下Rh

テスト時間:

0.1~999.9S

パッケージの詳細:

合板

ハイライト:

6 Stations Tensile Strength Testing Machine

0~40A Load Current Pull Force Tester

4~12V Load Voltage Cable and Wire Tester

製品の説明

Cable and Wire Tensile Strength Testing Machine

High Precision Pull Force Tester for Electrical Cables & Wires – UL 817 Standards Compliant

The Cable and Wire Pull Strength Tester is a high-precision device designed to evaluate the mechanical strength of plugs, connectors, and cables. By simulating real-world scenarios such as sudden pulls, rotations, and lifting loads, it ensures that wires, cables, and their connected components remain securely connected under stress, effectively preventing accidental disconnection.

Widely used in plug production lines, quality inspection laboratories, and power cable manufacturing, it is an ideal testing solution for ensuring the mechanical safety of electrical products.

International Reference Standards

UL 817: Requirements for sudden pull strength, rotational testing, and current load testing of plug and cord assemblies (UL817 No. 99.1-99.2 "Turning test", No. 100.1-100.3 "Sheath retention test")
ANSI/EIA 364-38B: Specifies a test procedure for the axial pull of cable clamps on electrical connectors to evaluate their tensile retention capabilities
IEC 60794-1-311:2024: Test method for tensile strength and elongation of optical fiber cable components (Method G11A)
EN 50289-3-16: Mechanical test standard for telecommunication cables, covering laboratory methods for determining the tensile properties of cables

Test Objects and Inspection Items

Applicable Objects

Power plugs, connector terminals
Household appliance cables (e.g., rice cooker, washing machine power cords)
Communication cables (network cables, fiber optic cables)
Automotive charging station cables (QC3.0 fast charging device cables)

Testable Items

Sudden tensile strength: Tests the connection strength between the plug and the conductor under simulated sudden tensile forces
Rotational fatigue: Tests the cable's durability under torsion
Current load performance: Verifies connection stability after applying current (e.g., 30A/12V)
Elongation and breaking strength: Analyzes the mechanical behavior of the cable as it stretches and deforms to fracture

Technical Parameters

Parameter	Specification
Power supply	AC 220V 50Hz
Load current	0~40A, Arbitrary adjustable
Load voltage	4~12V
Working station	6 stations
Test times	1~9999 times, can be preset
Test time	0.1~999.9S
Load weight	2.5 pound(lb), 3 pound(lb), 15 pound(lb) 6 pcs per each
Ambient temperature	0~40℃
Ambient humidity	less than 85%Rh
Reference standard	UL817 clause 99.1-99.2 Abrupt Pull Test, clause 100.1-100.3 Jacket retention test

Product Images

After Sale Service

Our professional working team and outstanding sales team are committed to providing our clients with products worldwide and guaranteeing fast and efficient after-sales services to meet various needs.

About Us

Guangzhou Hongce Equipment Co., Ltd is a leading company in inspection equipment industry, established in 2003 and located in Guangdong, China. Our company introduced advanced equipment, combined with the most advanced technology production processes, strict quality control system to control the entire process of production.

The company combined with a number of high-tech management personnel and advanced equipment, and together with the modern management, computer design and control, our products has reached the international advanced level. The company integrates R&D design, production, and sales into one cohesive unit, specializing in the manufacture of a diverse range of testing equipment, including flammability testing equipment, battery testing equipment, home appliance testing equipment, helium leak testing equipment, cable testing equipment, IP testing equipment, general testing equipment, as well as other non-standard testing equipment.

Our products enhance good selling at home and abroad, and have established supply relationships with a number of well-known companies.
