High-Accuracy Impact Testing Machine for IEC & GB Standards with 192KHZ Sampling Frequency Shock Test System

ブランド名:	HongCe
モデル番号:	HC-G829
MOQ:	1セット
価格:	Negotiatable
支払条件:	LC、T/T
供給能力:	1ヶ月あたり5セット

詳細情報

製品の説明

詳細情報

起源の場所:

中国

証明:

Third party calibration certificate(cost additional)

入力チャネル:

2チャンネル

サンプリング周波数:

192KHz

衝撃波形:

半分の正弦の波形

寸法:

1100MMx800MMx2500MM (カスタマイズ可能)

重さ:

1300kg

力:

1500W

パッケージの詳細:

合板

ハイライト:

High-Accuracy Impact Testing Machine

IEC & GB Standards Shock Test System

192KHZ Sampling Frequency Mechanical Shock Test Bench

製品の説明

Mechanical Impact Testing Machine for IEC & GB Standards

High-accuracy shock test system for components and assemblies with precise, repeatable impact waveforms for reliable product testing.

Product Introduction

The Mechanical Shock Test Bench is a high-reliability testing device designed for electronic and electrical components, automotive parts, connectors, and industrial components. It realistically reproduces transient impact environments during transportation, installation, and use, helping manufacturers identify structural risks before mass production.

Product Features

Stable mechanical impact structure with high long-term operational reliability
Precisely adjustable impact parameters including acceleration, pulse duration, and impact count
High repeatability for reliable data in type testing and conformity verification
Modular fixture design adaptable to various sample sizes and shapes
Intuitive operation with low maintenance and training costs
Compliance with multiple international testing standards including IEC, GB, and EN

International Standards Compliance

IEC 60068-2-27: Environmental testing - Shock tests with half-sine shock waveform
IEC 60068-2-29: Environmental testing - Bump tests for repeated mechanical shocks
GB/T 2423.5: Environmental testing for electrical and electronic products - Shock test methods
EN 60068-2-27: European standard equivalent to IEC shock test requirements

Technical Parameters

Test Item	Parameters
Motor	750W Three-phase Asynchronous Motor
Control Method	Computer Control
Drop Method	Free Fall
Drop Height	0~1500MM
Work Surface	350X350MM
Work Surface Material	High-strength High-Quality Aluminum Alloy
Maximum Load	25KG
Peak Acceleration	20~1500G
Acceleration Sensor Range	+2500G
Pulse Duration	0.5~30MS

Product Structure Analysis

Frequently Asked Questions

What is the difference between a mechanical impact test bench and a drop test?

Mechanical impact testing emphasizes controllable impact waveforms and acceleration parameters, resulting in more accurate data and suitability for standardized testing.

Does the test bench support customized impact parameters?

Yes, parameters can be customized according to the test object and standard requirements.

Can it be used in third-party testing laboratories?

Yes, the equipment is designed to comply with IEC/GB standards and meets laboratory usage needs.

Is the equipment installation complex?

The structure is mature, installation is simple, and complete video guidance is provided.

For more information about this equipment, please contact us. We offer one-stop customized solutions and quotations, providing quality at customized prices. Welcome to contact us!
